YW204HD 4 in 1 IRD

YW204HD 4 in 1 IRD support 4 IP and 1 ASI input, 4 channels decoding output with AVS+/H.265/H.264/MPEG2 decoding. It also support 8 HD-SDI/4 HDMI/4 CVBS/4 AES/EBU and 4 analog stereo output, and support 4K/1080P/1080I/720P/ 576I/480I resolution.

Key Features

  • Support IP/ASI input

  • Support CVBS/HDMI/SD/HD-SDI/AES/EBU/Analog Stereo/ASI/IP input

  • Support DRA/AC3/EAC3/AAC/MPEG audio decoding

  • Support AVS+/H.265/H.264/MPEG2 video decoding

  • Support AC3 passthrough

  • Support Biss_1/Biss_E descrambling mode

  • Support Closed caption/subtitle/Teletext function

  • Resolution can be automatically identified or manually set

  • Friendly user interface to facilitate the operation of the menu system and all operations can be completed on the LCD

  • B/S based web management

  • Support dynamic monitoring of  signal input strength and SNR and support signal lock-lose alarm

Specificatons

ASI Input/output

ASI input Interface

1*BNC input, 75Ω

ASI output interface

2*BNC input, 75Ω

Standard

DVB-ASI, EN50083-9

Bitrate

≤200Mb/s



IP Input/output

Interface

2*RJ-45, 1000 Base-T

Effective rate

900Mb/s (100 Based-T)

Frame length

(1-7)x188 adjustable byte

IP protocol

UDP/RTP, Unicast, Multicast

HDMI output

Interface

4*HDMI port(support 4K resolution and 1.4a frame rate)

Resolution and frame rate

4K30/1080P60/1080P50/1080I60/1080I50/720P60/720P50/576P/576I/480P/480I

Embed audio

1 stereo

Video decoding

Decoding format

MPEG-2/MPEG 4/H.264 AVC/H.265(HEVC)/AVS+

Audio decoding

Decoding format

MPEG-1 LayerI/II, MPEG-2 layer II, MPEG-2 AAC, MPEG-4 AAC LC, 2-CHANNEL/5.1 CHANNEL AC3/DRA/EAC3

HD/SD-SDI output

Interface

8*BNC, 75Ω

SD-SDI output

SMPTE 259M, 270Mb/s(10bit)

HD-SDI output

SMPTE 292M, 1.485Gbit/s(20bit)

output

Level 800mV+-20 p-p

Analog audio output

Interface

4*RCA, 4*XLR

Output audio format

Left, Right, Dual Mono, Stereo

Digital audio output

Interface

4*AES/EBU

Analog video output

Video interface

4*RCA, 75Ω

Output Level

1.0Vp-p±5%

CVBS format

PALBDGHI, PALN, NTSCM, PALN-C, NTSCM, NTSCM443, PALM, SECAM, NTSCMJ

Video SNR

≥56dB

Video sync amplitude

300±20mVP-P

Video amplitude characteristic

±0.8Db(4.8MHz); ±1dB(4.8-5MHz); ±0.5/-4dB(5.5MHz)

Video output amplitude

700±30mVP-P

Differential gain

≤8%

Data output

Subtitle

DVB/EBU

Teletext

DVB/EBU

Closed Caption

EIA 608, EIA 708, EIA 608-to-708

Local and remote management

Interface

1*RJ-45, 10/100 Base-T

Remote management

HTTP Web

Local management

Front pannel button and LED

Device upgrade

IP or USB

Miscellaneous

Dimension (W×L×H)

450mm×350mm×44mm

Net Weight

5Kg

Power

AC 90V~250V, 50/60Hz

Consumption

24W(Power supply without LBN)

Temperature

0~45(work)-10~60(Storage)

Humidity

10~90%(Non-Condensing)
