YW200-8A audio decoder supports 4 channels IP input, 1 channel ASI input and 8 channels audio decoding including DRA/AC3/AAC/MPEG, etc. Key Features Support IP/ASI input Support AES/EBU/Analog Stereo/ASI/IP input Support DRA/AC3/EAC3/AAC/MPEG audio decoding Resolution can be automatically identified or manually set Friendly user interface to facilitate the operation of the menu system and all operations can be completed on the LCD B/S based web management
Specificatons ASI input/output | ASI input | 1¡ÁBNC£¬75¦¸ | ASI output | 2¡ÁBNC£¬75¦¸ | standard | DVB-ASI£¬EN50083-9 | ASI input/output | ¡Ü200Mb/s | IP Input/output | Interface | 2¡ÁRJ-45£¬100/1000 Base-T | Effective rate | ¡Ü900Mb/s£¨1000 Base-T£© | Frame length | £¨1-7£©X188 adjustable byte | IP protocol | UDP/RTP£¬ Unicast¡¢Multicast | Audio decoding | standard | MPEG-1 layer I/II£¬MPEG-2 layer II,MPEG-2 AAC,MPEG-4 AAC LC 2-CHANNEL/5.1 CHANNEL AC3/DRA | Analog audio output | Interface | 8xMiniXLR(CANNON) | Output audio format | Left£¬Right£¬Dual Mono£¬Stereo | Digital audio output | Interface | 8xMiniAES/EBU(CANNON) | Local and remote management | Interface | 1¡ÁRJ-45£¬10/100 Base-T | Remote managemen | HTTP Web | Local management | Front pannel button and LED | Device upgrade | IP or USB | Miscellaneous | Dimension (W¡ÁL¡ÁH) | 450*350*44mm | Net Weight | 5KG | Power | AC 90V¡«250V£¬50/60Hz | Consumption | 24W | Temperature | 0~45¡æ(work)£»-10~60¡æ(Storage) | Humidity | 10~90%(Non-Condensing) |
|
